Midiplus Mirror USB Audio Interface with Advanced Audio Routing System

Midiplus Mirror USB Audio Interface with Advanced Audio Routing System

Mirror Audio Interface
A fun way to add visual flare as well as perfectly capture every detail of your performance. Mirror is an audio interface designed especially with your webcast self-karaoke channel in mind.Mirror is much more than just a fun novelty case. It brings crystal clarity to your web-stream with its high-quality analog to digital converters featuring 24bit depth and 192kHz sample rate.One combi 1/4" + XLR input provides connectivity for instruments and microphones alike.Universal compatibility is achieved with iOS, Android, Mac, and PC based webcasting platforms.Mirror is a part of Midiplus' Fancy series. A product line dedicated to provide playful styling as well as high-quality audio capture to self-k webcasters everywhere.

High Quality Audio Capture Designed for Live Streaming. Integrated Novelty Mirror + Light. Universally Compatible. Easily Connect : Mic, Guitar, Monitar and Phone

Features :

• 1 XLR+TRS interface combo + 1 TRS interface
• 2 headphone output interface
• 4 segment 3.5 mm interface (L as output, LR as input) cut-off for the input signal, reflecting the range the input signal in real time.
• Line/INST switch button, audio interface switch button, 48V phantom power supply button
• IOS/Android selector switch
• 2 knobs to control input gain, 1 knob to control the brightness of soft light, 1 knob to control phone output volume, 2 knobs to control headphone volume
• +48V Phantom Power
• LED level display
• USB 5V power, DC 5V/1A power supply

Specification :

Mic In

• Frequency Response : 20Hz – 20kHz +/-0.1 dB
• THD+N+Ratio : 0.0031% (FOR -1dBFS @1K)
• Equivalent Input Noise (EIN) : <-120dB
• Gain Range : -44dB-----+6dB
• Input Impedance : 2K Ohms
• Dynamic range : > 106dB(A)
• Max input Level : +6 dBu

Line in 1/2

• Frequency Response : 20Hz – 20kHz +/-0.1 dB
• THD+N+Ratio : 0.0034% (FOR -1dBFS @1K)
• Equivalent Input Noise (EIN) : <-120dB
• Gain Range : -30dB-----+20dB
• Crosstalk : -99dB ( FOR 0dBFS @1K)
• Dynamic range : > 106dB(A)
• Input Impedance : 10K Ohms
• Max Input Level : +20 dBu

INSTRUMENT IN

• Frequency Response : 20Hz – 20kHz +/-0.13dB
• THD+N+Ratio : 0.067% (FOR -1dBFS @1K)
• Equivalent Input Noise (EIN) : <-110dB
• Gain Range : -37dB ~ +13dB
• Dynamic range : > 99dB(A)
• Input Impedance : 1M Ohms
• Max Input Level : +13 dBu

Headphone 1/2 Outputs

• Frequency Response : 20Hz – 20kHz +/-0.25dB (- 1dBFS @1K For 32 Ohms Max out)
• Crosstalk : -60dB (- 1dBFS @1K For 32 Ohms Max out)
• THD+N+Ratio : <0.043% (- 1dBFS @1K For 32 Ohms Max out)
• Dynamic range : > 90dB(A) (- 1dBFS For 32 Ohms Max out)
• output Impedance : 10 Ohms
• Output maximum power : 150mW (0dBFS For 32 Ohms Max out)
• THD+N+Ratio (Max Output Level) : <0.05% (0dBFS @1K For 32 Ohms FOR 150mW)

Phone Out

• Frequency Response : 20Hz – 20kHz +/-0.2 dB
• THD+N+Ratio : 0.0028% (FOR -0dBFS @1K)
• Equivalent Output Noise (EIN) : <-100dB
• Max Input Level : -6 dBu

Digital Performance

• A-D Dynamic Range : 105dB A-werghted (all inputs) Converter chipset A-D dynamic range 114dB
• D-A Dynamic Range : 104dB A-werghted (all outputs) Converter chipset D-A dynamic range 114dB
• Supported sample rates : 44.1KHz 48KHz 88.2KHz 96KHz 192KHz
