LD Systems DEEP2 2400 X 2 x 1200 Watts 2 Ohm Amp PA Power Amplifier (DP2400X DP-2400X DP 2400X)

LD Systems DEEP2 2400 X 2 x 1200 Watts 2 Ohm Amp PA Power Amplifier (DP2400X DP-2400X DP 2400X)

The DP2400X is the newest member of the DEEP2 family of power amplifiers.
In response to requests by many customers, we expanded this series with a new, powerful amplifier that is also compatible with 2-ohm systems. The key specifications are 2 x 1200 W at 2 ohms, 2 x 950 W at 4 ohms and 2 x 600 W at 8 ohms RMS power. Like the other power amplifiers in the DEEP2 series, the DP2400X uses class H circuitry powered by a conventional power supply. The protective circuitry is also identical with that used in the DEEP2 series. It also follows the DEEP2 design in its integration of two temperature-dependent two step cooling fans. One special feature is a switchable 12 dB low-cut and/or 12 dB low-pass filter adjustable from 25 Hz to 150 Hz on both channels. This makes it possible to use the DP2400X as a bass amp or even realize a powerful bi-amping system. With the filters switched off, it becomes a conventional 2 channel power amp.

Specification:

• Type  :  PA Power Amplifiers
• Rated ouput power (1kHz @ 2 Ohms)  :  2 x 1200 W
• Rated ouput power (1kHz @ 4 Ohms)  :  2 x 950 W
• Rated ouput power (1kHz @ 8 Ohms)  :  2 x 600 W
• Rated ouput power (1 kHz @ 4 Ohms, bridged)  :  2200 W
• Rated ouput power (1kHz @ 8 Ohms, bridged)  :  1800 W
• Output circuitry  :  Class H
• Frequency response  :  20 - 20000
• Total Harmonic Distortion (THD)  :  < 0.1 %
• Signal-to-noise ratio  :  106 dB
• Damping factor (20Hz-500Hz @8ohm) :   > 450
• Crosstalk  :  >76 dB
• Gain  :  39 dB
• Input sensitivity  :  0.775 V
• Protection circuits :  clip limiter, DC protection, short circuit, thermal overload
• Controls  :  2 x highpass/lowpass (switchable), 2 x volume, bridge/stereo mode selector, ground lift, mains switch (on/off)
• Indicators  :  level, Limit, Power, Protect (protection circuit engaged), Signal
• Loudspeaker outputs  :  2
• Speaker output connections  :  Speakon compatible, Terminal posts
• Cooling  :  highly efficient, automatic
• Operating voltage  :  transformer
• Operating voltage  :  230 V AC / 50-60 Hz
• Weight  :  17,6 kg
• Features  :  Volex mains socket
